This Taco Shell & Tube Heat Exchanger, model G8416L, is a liquid to liquid heat exchanger designed for efficient heat transfer. With a nominal shell diameter of 8 inches, this heat exchanger features 4 tube passes and a tube bundle length of 96 inches. The tubes are made of copper, with a size of 3/4 OD x .035 (20 Ga) wall SB75. The heat transfer medium flows through these tubes, allowing for effective heat exchange. The connection type is channel - flanged - W/O cover, providing secure and convenient connections. The tube plate material is steel tube plate, ensuring durability and stability. Steel separators are used in this heat exchanger to enhance the separation process. With a working pressure of 150 psi, this Taco Shell & Tube Heat Exchanger is suitable for various industrial applications where efficient and reliable heat transfer is required.
Taco Shell & Tube Heat Exchangers Overview
Taco Shell & Tube Heat Exchangers are equipment used in HVAC systems and various industrial applications for the purpose of transferring heat between two fluids. These exchangers are composed of a large outer shell and an inner tube bundle. The arrangement allows one fluid to flow through the tubes while a second fluid circulates outside the tubes but within the shell. As they pass each other, heat exchange occurs, with the fluid inside the tubes either gaining or losing heat from the fluid in the shell. Taco Shell & Tube Heat Exchangers are noted for their durable construction, effectiveness in heat transfer, and ease of maintenance, including the straightforward process of replacing the tube bundle.
Note: product image is generic
