This Taco Shell & Tube Heat Exchanger, model G10420L, is a liquid to liquid heat exchanger designed for efficient heat transfer. With a nominal shell diameter of 10 inches and four tube passes, this heat exchanger ensures optimal performance. The tube bundle length measures 120 inches, providing ample surface area for effective heat exchange. The tubes are made of copper with a size of 3/4 OD x .035 (20 Ga) wall thickness, specifically SB75 tubes. The connections are threaded for easy installation and maintenance. The tube plate and separators are constructed from steel, ensuring durability and longevity. This heat exchanger can withstand a working pressure of up to 150 psi, making it suitable for various applications requiring high-pressure capabilities.
Taco Shell & Tube Heat Exchangers Overview
Taco Shell & Tube Heat Exchangers are equipment used in HVAC systems and various industrial applications for the purpose of transferring heat between two fluids. These exchangers are composed of a large outer shell and an inner tube bundle. The arrangement allows one fluid to flow through the tubes while a second fluid circulates outside the tubes but within the shell. As they pass each other, heat exchange occurs, with the fluid inside the tubes either gaining or losing heat from the fluid in the shell. Taco Shell & Tube Heat Exchangers are noted for their durable construction, effectiveness in heat transfer, and ease of maintenance, including the straightforward process of replacing the tube bundle.
Note: product image is generic
