This Taco Shell & Tube Heat Exchanger, model G16416L, is a liquid to liquid heat exchanger designed for efficient heat transfer. With a nominal shell diameter of 16 inches, this heat exchanger is capable of handling high volumes of liquid. It features 4 tube passes, allowing for multiple opportunities for heat exchange. The tube bundle length is 96 inches, providing ample surface area for maximum heat transfer efficiency. The tubes are made of copper with a size of 3/4 OD x .035 (20 Ga) wall thickness SB75 tubes, ensuring durability and excellent thermal conductivity. The connection type is channel-flanged without a cover, allowing for easy installation and maintenance. The tube plate and separators are made of steel, providing strength and stability to the overall structure. This heat exchanger has a working pressure rating of 150 psi, making it suitable for various industrial applications where high pressure conditions are encountered.
Taco Shell & Tube Heat Exchangers Overview
Taco Shell & Tube Heat Exchangers are equipment used in HVAC systems and various industrial applications for the purpose of transferring heat between two fluids. These exchangers are composed of a large outer shell and an inner tube bundle. The arrangement allows one fluid to flow through the tubes while a second fluid circulates outside the tubes but within the shell. As they pass each other, heat exchange occurs, with the fluid inside the tubes either gaining or losing heat from the fluid in the shell. Taco Shell & Tube Heat Exchangers are noted for their durable construction, effectiveness in heat transfer, and ease of maintenance, including the straightforward process of replacing the tube bundle.
Note: product image is generic
