This Taco Shell & Tube Heat Exchanger, model G4204S, is designed with a nominal shell diameter of 4 inches. It features a two-pass tube configuration, allowing for efficient heat transfer. The tube bundle length measures 24 inches, providing ample surface area for maximum heat exchange. The tubes are made of copper and have a size of 3/4 OD x .049 (18 Ga) wall SB75, ensuring durability and optimal performance. This heat exchanger is specifically designed for steam to liquid heat transfer applications. It utilizes threaded connections for easy installation and maintenance. The tube plate is constructed from steel, offering strength and stability. Additionally, the separators in this heat exchanger are also made of steel. With a working pressure rating of 150 psi, this Taco Shell & Tube Heat Exchanger is built to withstand demanding operating conditions while efficiently transferring heat between the steam and liquid mediums.
Taco Shell & Tube Heat Exchangers Overview
Taco Shell & Tube Heat Exchangers are equipment used in HVAC systems and various industrial applications for the purpose of transferring heat between two fluids. These exchangers are composed of a large outer shell and an inner tube bundle. The arrangement allows one fluid to flow through the tubes while a second fluid circulates outside the tubes but within the shell. As they pass each other, heat exchange occurs, with the fluid inside the tubes either gaining or losing heat from the fluid in the shell. Taco Shell & Tube Heat Exchangers are noted for their durable construction, effectiveness in heat transfer, and ease of maintenance, including the straightforward process of replacing the tube bundle.
