This in-line circulator consists of stainless steel construction for the casing and impeller, paired with a replaceable cartridge bearing assembly. The unit includes an alloy steel shaft with a cupro-nickel shaft sleeve and a two-piece carbon and ceramic mechanical seal. It accommodates piping connections from 3/4 to 1 1/2 inches and comes equipped with companion flanges. The internal cartridge bearing design isolates the bearings from system fluid temperatures, while the dynamically and hydraulically balanced impeller maintains stability during operation.
The motor operates at 1/8 HP and 1750 RPM, powered by a 115V 1PH supply. Maintenance-free operation is supported by permanently sealed, grease-lubricated motor ball bearings. Utilizing a rear pull-out design, the assembly permits complete removal of the motor and rotating components for servicing without disturbing the connected piping layout.
