Taco SCI Series Close-Coupled End Suction Pumps

Integrated Close-Coupled Pumping for Reliable, Responsive System Performance

Taco SCI Series close-coupled end suction pumps are designed to deliver reliability, easy installation, and responsive system performance for heating, air conditioning, pressure boosting, cooling water transfer, and water supply applications. With an integrated pump and drive design, the SCI Series automatically responds to changes in system demand without requiring remote sensors or complex wiring.

Built for efficient installation and long-term serviceability, SCI Series pumps include an easy-to-replace slip-on shaft sleeve that simplifies field seal maintenance and helps reduce maintenance costs. Taco’s exclusive dry shaft design protects the pump shaft by preventing contact with the circulating fluid, reducing the need for expensive corrosion-resistant shaft materials in many applications.

Flush seal line taps allow a filter to be installed to help protect the seal from non-condensable particles found in open systems. Standard pressure tappings on the suction and discharge connections make system monitoring, testing, and service more convenient.

The SCI Series also supports multiple operating modes, including constant flow, constant pressure, flow compensation, and duplex pump alternation. Parallel pumping operation is available with Taco’s Modulating Pump Controller, giving system designers and building operators added flexibility for changing load conditions.

Select Taco products also feature eLink® connectivity, Taco Comfort Solutions’ cloud-based service platform. eLink gives users access to device data, performance information, status updates, monitoring, support, and control from a mobile phone, tablet, or laptop. Products featuring eLink may support application-specific functions for support, monitoring, or controls.

Product Features

• Close-coupled end suction pump with integrated pump and drive (Self-Sensing with Pro Balance Control)

• Designed for reliable operation and easy installation

• Automatically responds to system demand changes

• No remote sensors required

• No complex wiring required

• Multiple operating modes, including constant flow, constant pressure, flow
• compensation, and duplex pump alternation

• Parallel pumping operation available with Taco’s Modulating Pump Controller

• Easy-to-replace slip-on shaft sleeve simplifies field seal maintenance

• Helps reduce maintenance costs

• Dry shaft design protects the pump shaft from system fluid

• Helps reduce the need for corrosion-resistant shaft materials

• Flush seal line taps allow filter installation to help protect the seal

• Standard pressure tappings on suction and discharge connections

• eLink® connectivity available on select Taco products for support, monitoring, and controls

Performance Data

• Flow range: 10 to 2,500 GPM

• Head range: 1 to 390 feet

• Horsepower range: 1/2 to 60 HP

• Pump sizes: 1-1/2" to 6"

Common Applications

• Hot water heating systems

• Closed cooling circuits

• Air conditioning systems

• Hydronic heating and cooling

• Water/glycol systems with concentrations up to 50%

• Solar systems

• Geothermal systems

• Pressure boosting

• Cooling water transfer

• Water supply
